This D'n'A series (Digital and Analogue) cable is designed to be suitable for both digital and analogue audio signals, with an impedance of 100 ohms which has been proven to be suitable for AES/EBU digital audio as well as analogue microphone and line level signals. Wire insulation is polypropylene, which shrinks back minimally during soldering (considerably less than PVC or polyethylene).
It is a smaller version of the classic Canford FST, for use where space is at a premium. As with the original, the foil is bonded to the outer jacket for easy stripping.
Technical Specification:
Conductors: 25/0.1mm (0.20mm sq.) bare copper
Insulation: Foamed polypropylene, 1.46mm O.D., red, black
Construction: Two cores twisted together with 25/0.1mm bare copper drain wire
Screen: Aluminium/polyester foil tape, bonded to jacket
Jacket: PVC, O.D. 3.7mm (wall thickness 0.3mm), black, printed with metre markings
Impedance: 100 ohms
Capacitance: 41pF/metre core to core, 85pF/metre core to core +screen (+/- 5pF/metre)
Conductor resistance: 101 ohms/km
Weight: 1.26kg/100m
